TH360 V2 ARGB Snow has a new industrial cap with an infinity mirror light design, bringing a new vibe to the TH series. Equipped with three CT120 ARGB White fans, the TH360 V2 ARGB Snow is suitable for medium to large chassis that fit 360mm AIOs, and for those who seek to control lighting effects through 5V motherboard-controlled software.

No matter the build, We’ve got you covered

New Version, New Design
TH V2 ARGB Snow was given an industrial look to freshen up the 360-degree rotational cap. Adding Infinity Mirror Lighting to this series can bring more diverse visual effects to the build and gives more depth than it looks.
The TH V2 ARGB Snow Series is now ready for all types of builds; the series has three 120mm fan models, including the TH 120/ 240/ 360 V2 ARGB Snow, and two 140mm fan models, including TH 280/ 420 V2 ARGB Snow.

Enhanced Cooling Surface With A Compact Design
The TH V2 ARGB Snow Series has a 27mm slim radiator with a thickened 20mm copper chamber, ensuring the same easy installation but with even better cooling performance.

Less Cable, Less Mess
The new cable-integrated daisy-chain design allows the fans to be directly connected, so it minimizes demands of 4-pin PWM and 3-pin ARGB ports on your motherboard and shortens the cable length between the fans. We’ve also included one PWM cable and one ARGB cable for you to easily manage your cables while assembling your build.

Keeping Your Cables in Place
You might have experienced easily detached 5V ARGB cables when you assemble your builds. Worry not; this 5V ARGB Connector Clip can guarantee that the cables are correctly connected and won’t get loose in unexpected conditions.

Keep it COLD with Copper
The high-performance copper base plate accelerates heat conductivity. The high-quality and reliable pump enables maximum water circulation, keeping the copper plate continuously cool. The low evaporation tube effectively decreases the loss of coolant; therefore, no refill is required.

Any CPU Can Be the Right CPU
The package includes brackets for the latest Intel and AMD CPU sockets to be compatible with the most modern CPU platforms, including the latest Intel LGA1700 and AMD AM5 CPUs.
Compatibility list:
Intel: LGA 2066/2011/1700/1200/1156/1155/1151/1150
AMD: AM5/AM4/AM3+/AM3/AM2+/AM2

Sync with Motherboard RGB Software
Designed to synchronize with ASUS Aura Sync, GIGABYTE RGB Fusion, MSI Mystic Light Sync, and ASRock Polychrome. It supports motherboards with a 5V addressable RGB header, allowing you to control the lights directly from the software mentioned above without installing any extra lighting software or controllers. For more details, please visit ASUS, GIGABYTE, MSI, and ASRock official websites.

Performance
Suitable location: Processor
Type: Liquid cooling kit
Fan diameter: 36 cm
Supported processor sockets: LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, LGA 2011 (Socket R), LGA 2066, Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket AM5
Maximum airflow: 57.05 cfm
Minimum air pressure: 2.23 mmH2O
Pulse-width modulation (PWM) support: Yes
Bearing type: Hydraulic
Fan noise level (max): 25.8 dB
Pump connector: 4-pin
Quantity per pack: 1 pc(s)
Pump motor speed (min): 1500 RPM
Pump motor speed (max): 3300 RPM
Fan speed (min): 500 RPM
Fan speed (max): 2000 RPM
Fan static pressure: 2.23 mmH2O
Fan's mean time to failure (MTTF): 40000 h
Design
Product colour: White
Radiator material: Aluminum
Number of fans: 3 fan(s)
Illumination LED: Yes
Illumination colour: Blue, Red
Water block material: Copper
Power
Fan power consumption: 1.55 W
Rated current: 0.11 A
Pump voltage: 12/5 V
Pump current: 0.43 mA
Fan voltage: 12 V
Fan current: 0.31 A
Weight & dimensions
Radiator width: 39.6 cm
Radiator depth: 2.7 cm
Radiator height: 12 cm
Tube length: 46 cm
Fan dimensions (W x D x H): 120 x 120 x 25 mm
