Gigabyte UD750GM PG5 V2 ICE 750W 80+ Gold - GP-UD750GM PG5 ICE
GIGABYTE UD750GM PG5 V2 ICE Netzteil – PCIe Gen 5.1, 80 PLUS Gold, Vollmodulares Design, 120-mm-Fan, ATX 3.1-kompatibel, EU-Stecker. Total Power: 750 W, AC Input Voltage: 100 - 240 V, AC Input Frequency: 50/60 Hz. Motherboard Connector: 20+4 pin ATX, Motherboard Cable Length: 61 cm, PCI Express-Stromanschlüsse (12+4-polig) Kabellänge: 700 mm. Purpose: PC, Power Supply (PSU) Form Factor: ATX, 80 PLUS Certification: 80 PLUS Gold. Colour: White, Cooling: Active, Fan Diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 86 mm
SKU :
21355252Barcode :
4719331556310MPN :
GP-UD750GM PG5 ICEGIGABYTE UD750GM PG5 V2 ICE Power Supply Unit- PCIe Gen 5.1, 80 PLUS Gold, Fully Modular Design, 120mm Fan, ATX 3.1 compatible, EU Plug. Total power: 750 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, PCI Express power connectors (12+4 pin) cable length: 700 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: White, Cooling type: Active, Fan diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 86 mm
Total power: 750 W
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Input current: 12 - 6.5 A
Power factor: 0.9
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 105 W
Combined power (+12V): 750 W
Combined power (+5V): 105 W
Combined power (-12V): 3.6 W
Combined power (+5Vsb): 15 W
Max output current (+3.3V): 20 A
Max output current (+12V): 62.5 A
Max output current (+5V): 20 A
Max output current (-12V): 0.3 A
Max output current (+5Vsb): 3 A
Hold time: 16 ms
Efficiency: 90%
Power protection features: Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Ports & interfaces
Motherboard power connector: 20+4 pin ATX
Motherboard power cable length: 61 cm
Number of SATA power connectors: 8
Peripheral (Molex) power connectors (4-pin): 3
PCI Express power connectors (6+2 pin): 4
PCI Express power connectors (12+4 pin): 1
PCI Express power connectors (12+4 pin) cable length: 700 mm
PCI Express power cable length: 60 cm
CPU power connector (4+4 pin): Yes
CPU power cable length: 65 cm
Floppy drive power connector: 1
PCI Express connector: Yes
Number of EPS connectors: 2
Cabling type: Fully-Modular
Performance
80 PLUS certification: 80 PLUS Gold
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
Bearing technology: HYB
Mean time between failures (MTBF): 100000 h
Design
Product colour: White
Cooling type: Active
Fan diameter: 12 cm
Number of fans: 1 fan(s)
On/off switch: Yes
Weight & dimensions
Width: 150 mm
Depth: 140 mm
Height: 86 mm
Weight: 2.34 kg
Packaging data
Package width: 618 mm
Package depth: 269 mm
Package height: 211 mm
Package weight: 2.5 kg
Package type: Box
Logistics data
Warranty period: 5 year(s)
| General Information | |
|---|---|
| Manufacturer | Gigabyte |
| Power Supply | 750W |
| Colour | Gold |
| PSU Certification | 80+ Gold |
| Uncategorized | |
| PSU Modularity | Modular |
