Intel Xeon E-2486 LGA4677 - CM8071505024814
Intel Xeon E-2486. Prozessorfamilie: Intel Xeon E, Processor Socket: LGA 1700, Verpackungsart: Einschub. Memory Channels: Dual-channel, Max Internal Memory, vom Prozessor unterstützt: 128 GB, Speichertypen, vom Prozessor unterstützt: DDR5-SDRAM. Marktsegment: Server, Nutzungsbedingungen: Server/Enterprise, PCI Express Konfigurationen: 2x8+1x4, 1x16+1x4. Intel® Turbo Boost Max Technology 3.0 frequency: 5,6 GHz, Intel® Turbo Boost Technology 2.0 frequency: 5,6 GHz, Mikroprozessor PCIe Revision: Gen 5. Max RAM: 128 GB
SKU :
21238335Barcode :
8592978518387MPN :
CM8071505024814Intel Xeon E-2486 LGA4677 - CM8071505024814
Intel Xeon E processor rated 95W TDP boosting to 5.6GHz — dependable performance for desktops, workstations and servers.
Technical Specifications
ProzessorProcessor Manufacturer: Intel
Prozessor: E-2486
Grundfrequenz des Prozessors: 3,5 GHz
Prozessorfamilie: Intel Xeon E
Anzahl Prozessorkerne: 6
Processor Socket: LGA 1700
Prozessor-Threads: 12
Systembus-Rate: 16 GT/s
Prozessorbetriebsmodi: 64-Bit
Leistungskerne: 6
Prozessor Boost-Frequenz: 5,6 GHz
Prozessor-Cache: 18 MB
Thermal Design Power (TDP): 95 W
Verpackungsart: Einschub
Stepping: B0
Maximale Anzahl DMI-Spuren: 8
Prozessor Codename: Raptor Lake
ARK Prozessorerkennung: 236185
Speicher
Max Internal Memory, vom Prozessor unterstützt: 128 GB
Speichertypen, vom Prozessor unterstützt: DDR5-SDRAM
Memory Channels: Dual-channel
ECC: Ja
Grafik
Eingebaute Grafikadapter: Nein
Separater Grafikadapter: Nein
Integrated Graphics Model: Nicht verfügbar
Separates Graphics Model: Nicht verfügbar
Merkmale
Execute Disable Bit: Ja
Leerlauf Zustände: Ja
Thermal-Überwachungstechnologien: Ja
Marktsegment: Server
Nutzungsbedingungen: Server/Enterprise
Maximale Anzahl der PCI-Express-Lanes: 20
PCI-Express-Slots-Version: 5.0
PCI Express Konfigurationen: 2x8+1x4, 1x16+1x4
Unterstützte Befehlssätze: AVX 2.0, SSE4.1, SSE4.2
Skalierbarkeit: 1S
CPU Konfiguration (max): 1
Eingebettete Optionen verfügbar: Nein
Exportkontroll-Klassifizierungsnummer (ECCN): 5A992C
Warenklassifizierungssystem zur automatisierten Nachverfolgung (CCATS): 740.17B1
Prozessor Besonderheiten
Intel® Hyper-Threading-Technik (Intel® HT Technology): Ja
Intel® Turbo-Boost-Technologie: 2.0
Intel® AES New Instructions (Intel® AES-NI): Ja
Verbesserte Intel SpeedStep Technologie: Ja
Intel® Trusted-Execution-Technik: Ja
Intel® Turbo Boost Max Technology 3.0 frequency: 5,6 GHz
Intel® Turbo Boost Technology 2.0 frequency: 5,6 GHz
Intel® Transactional Synchronization Extensions: Nein
Intel® Total Memory Encryption: Ja
Intel® VT-x mit Extended Page Tables (EPT): Ja
Intel® Sicherer Schlüssel: Ja
Intel® OS Guard: Ja
Intel® 64: Ja
Intel® Virtualization Technologie (VT-X): Ja
Intel® Virtualisierungstechnik für direkte I/O (VT-d): Ja
Intel Turbo Boost Max Technology 3.0: Ja
Intel® Boot Guard: Ja
Modusbasierte Execute Control (MBE): Ja
Intel® Optane™ DC Persistent Memory unterstützt: Nein
Intel® Virtualisierungstechnik mit Umleitungsschutz (VT-rp): Ja
Mikroprozessor PCIe Revision: Gen 5
Intel® Total Memory Encryption - Multi Key: Ja
Betriebsbedingungen
Tjunction: 100 °C
Logistikdaten
Warentarifnummer (HS): 8542310001
Technische Details
Startdatum: Q4'23
Status: Launched
Instandhaltungsstatus: Baseline Servicing
Sonstige Funktionen
Max RAM: 128 GB
| General Information | |
|---|---|
| Manufacturer | Intel |
| Condition | |
| Condition | Brand New |
| CPU | |
| CPU Manufacturer | Intel |
| CPU Family | Xeon E |
| CPU Cores | N/A |
| CPU Threads | 12 |
| CPU Base Clock | 3.5GHz |
| CPU Boost Clock | 5.6GHz |
| CPU TDP | 95W |
| Processor Socket | LGA4677 |
| Integrated Graphics | No |
| Memory | |
| RAM Technology | DDR5 |
